ALUSPHERE – węże ceramiczne o ekstremalnej odporności na ścieranie
ALUSPHERE ceramic hoses are used for pneumatic conveying of dry abrasive materials such as dry cement, coal dust, coal, coke, solid alternative fuels, steel shot, glass aggregate, etc. Used in steel mills, coking plants, power plants, cement plants, mines, glass works, abrasive material plants, and insulation material plants. There are two variants of the hose, delivery and suction-delivery.
One of their advantages is the very long service life in these applications – a traditional abrasion-resistant rubber hose will only last a few days, while ALUSPHERE hose can work for several months under the same conditions.
Advantages
ALUSPHERE ceramic delivery hose
| Inner layer | ceramic balls embedded in black NR rubber |
|---|---|
| Reinforcement | synthetic cord |
| Outer layer | black SBR / NR rubber |
| Working temperature | from -30⁰C to +80⁰C |
| Working pressure | 12 bar |
ALUSPHERE SPO 10 SF ceramic suction-delivery hose
| Inner layer | ceramic balls embedded in black NR rubber |
|---|---|
| Reinforcement | synthetic cord, steel wire helix |
| Outer layer | black SBR / NR rubber |
| Working temperature | from -30⁰C to +80⁰C |
| Working pressure | 8-10 bar |
Examples of applications
Conveying pulverised coal in steel mills
Transfer of alternative fuel in cement works
Assembly of ALUSPHERE hose
A standard ALUSPHERE hose assembly, with special fittings mounted on the outside of the hose – like for typical sandblasting couplings (couplings available on special request).
GHIBLI split flange system
Split flange system designed for suction-delivery hoses mounted on the outer layer of the hose – no contact between the medium and the fitting.
