Is the Flexible rubber air nozzle, series 319 safe for use on delicate surfaces and how is airflow adjusted without contact?

Yes. The Flexible rubber air nozzle, series 319 is safe for use on delicate surfaces . itâs specifically designed to remove contaminants without direct hard contact, reducing risk of scratching or damage. Airflow is adjusted without touching the surface by bending the flexible rubber nozzle: changing the bend alters the internal flow path and restricts or opens the outlet, which regulates the volume and direction of compressed air. Key specs supporting safe, non-contact use: 2 mm nozzle opening, nominal flow 200 l/min at 6 bar, operating pressure 1â6 bar, max 10 bar, and operating temperature â10Â°C to +50Â°C. Connection options: 6 mm or 9 mm hose end or EUROSTANDARD 7.2 plug.

Can the Flexible rubber air nozzle, series 319 be used at different pressures and what is its maximum and recommended operating pressure?

Can the Flexible rubber air nozzle, series 319 be used at different pressures and what is its maximum and recommended operating pressure? Yes - the Flexible rubber air nozzle, series 319 can be used across a range of pressures. Its maximum allowable pressure is 10 bar, while the recommended operating pressure range is 1â6 bar (nominal flow: 200 l/min at 6 bar).

How do I connect the Flexible rubber air nozzle, series 319 to different hose sizes or a EUROSTANDARD 7.2 plug?

Flexible rubber air nozzle, series 319 can be connected in three ways depending on the version you have: - Hose end 6 mm: push a 6 mm internal-diameter hose onto the 6 mm barb until it seats fully. Secure with a suitable hose clamp (spring or worm-gear) to prevent blow-off at operating pressures (1â6 bar). Check for leaks before use. - Hose end 9 mm: same procedure as above but with a 9 mm internal-diameter hose. Use a clamp sized for 9 mm hose to ensure a tight, safe connection. - EUROSTANDARD 7.2 plug: insert the EUROSTANDARD 7.2 plug into the matching female connector until it clicks or seats securely. Ensure the mating fitting is rated for the nozzleâs maximum pressure (10 bar) and test the connection at low pressure first. Notes for all connections: - Ensure the hose, clamp and mating fittings are rated for the nozzleâs operating pressure and temperature range (â10Â°C to +50Â°C). - The nozzle opening is 2 mm and nominal flow is â200 l/min at 6 bar; avoid exceeding the maximum pressure of 10 bar. - For delicate surfaces, use flow regulation by gently bending the flexible nozzle rather than increasing pressure.

Flexible rubber air nozzle, series 319

Air guns, All products/

Additional information

Flexible rubber nozzle for compressed air, designed for quick removal of all contaminants from surfaces. Flow regulation through bending of the nozzle. It performs excellently in situations where we deal with delicate surfaces prone to damage from direct contact. Depending on the connection, we distinguish between a nozzle with a hose end of 6 mm and 9 mm diameter or a EUROSTANDARD 7.2 plug. Nozzle opening diameter: 2 mm. Nominal flow: 200 l/min at 6 bar pressure. Maximum pressure: 10 bar. Operating pressure: 1 ÷ 6 bar. Operating temperature: from -10°C to +50°C.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
EW-31911	Rubber nozzle, hole diameter 2 mm, hose end 6 mm	-	10	In stock	Enquiry
EW-31917	Rubber nozzle, hole diameter 2 mm, hose end 9 mm	-	10	In stock	Enquiry
EW-31941	Rubber nozzle, hole diameter 2 mm, plug DN 7.2	-	10	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

Flexible rubber nozzle for compressed air, designed for quick removal of all contaminants from surfaces. Flow regulation through bending of the nozzle. It performs excellently in situations where we deal with delicate surfaces prone to damage from direct contact. Depending on the connection, we distinguish between a nozzle with a hose end of 6 mm and 9 mm diameter or a EUROSTANDARD 7.2 plug. Nozzle opening diameter: 2 mm. Nominal flow: 200 l/min at 6 bar pressure. Maximum pressure: 10 bar. Operating pressure: 1 ÷ 6 bar. Operating temperature: from -10°C to +50°C.
