Hydraulic pumps

  • Hydraulic pumps

Compact build square flanges with pitch diameter 30, 35, 40, 51, 55 mm and BSP or metric connection threads. Widely used for pump connection. Available with a set of screws, orings and washers as a standard. Made of zinc plated carbon steel or aluminium. Depending on type maximum working pressure to 315 bar.

budowa_pompy_hydraulicznej zębatej

  1. drive gear
  2. drive shaft
  3. driven gear
  4. body
  5. mounting plate
  6. rear cover
  7. bearing block sealing
  8. sealing rings
  9. bearing block
  10. static seal
  11. bolts
Types of gear pumps

Group Displacement [cm3/rev] Cobstruction
1 0,7 ÷ 8 mounting plate, body and rear cover made of aluminium
2 4 ÷ 30 mounting plate, body and rear cover made of aluminium
3 22 ÷ 55 cast iron mounting plate and rear cover, body made of aluminium

Design versions

Group Type Drive shaft Mounting plate Connections
1 01 taper 1:8 rectangular plate Ø25,4 mm BSP threaded connections
03 taper 1:8 rectangular plate Ø25,4 mm flange connections
2 01 taper 1:8 rectangular plate Ø36,5 mm BSP threaded connections
02 taper 1:8 rectangular plate Ø36,5 mm flange connections
04 taper 1:5 rectangular plate Ø80 mm flange connections
3 01 taper 1:8 rectangular plate Ø50,8 mm BSP threaded connections
02 taper 1:8 rectangular plate Ø50,8 mm flange connections

Catalogue
Download

Sales Network
Check

E-shop
See more

Inquiry
Send

List of products:

BTD1 gear pumps

BTD1 gear pumps; group 1 aluminium pumps with rectangular plate

BTD2 gear pumps

BTD2 gear pumps; group 2 aluminium pumps with rectangular plate

BTD3 gear pumps

BTD3 gear pumps; group 3 aluminium pumps with rectangular plate

Pump flange connectors

Pump flange connectors
