Is the 90Â° quick coupling socket for injection molds with hose end without valve, DYROS series 90 compatible with compressed air and cooling liquids at 15 bar?

Yes. The 90Â° quick coupling socket for injection molds with hose end without valve, DYROS series 90 is specified for cooling liquids in plastic processing and for compressed air installations, with a working pressure of 15 bar. Its construction.brass body, treated stainless steel retaining rings/springs/balls, and Viton sealing.makes it suitable for both compressed air and cooling liquids at that pressure.

90° quick coupling socket for injection molds with hose end without valve, DYROS series 90

Additional information

Material	B – brass (bronze)

90° quick coupling socket DYROS series 90 with hose end without valve. Designed for cooling liquids in plastic processing, compressed air installations, gas cylinder applications, and other technical fields. Material: all components are made of brass, while the retaining rings, springs, and balls are made of treated stainless steel. Sealing: viton. Working pressure: 15 bar.

List of product variants

Article number	Product variant name	Nominal inner diameter	Working pressure [bar]	Enquiry	Catalogue
DY-VK918-90-OV	90° socket DN 9 with 1/2" hose connection, without valve	12	15

90° quick coupling socket DYROS series 90 with hose end without valve. Designed for cooling liquids in plastic processing, compressed air installations, gas cylinder applications, and other technical fields. Material: all components are made of brass, while the retaining rings, springs, and balls are made of treated stainless steel. Sealing: viton. Working pressure: 15 bar.
