Is the DKL 90Â° hydraulic end, type ZMW211, light series, carbon steel compatible with standard crimping sleeves for industrial hydraulic hoses?

Yes. The DKL 90Â° hydraulic end, type ZMW211, light series, carbon steel is compatible with standard crimping sleeves for industrial hydraulic hoses . provided the sleeve is matched to the hose type and dimensions. The product description explicitly states it is designed for crimping in hydraulic and industrial hoses using a crimping sleeve suitable for the hose type. Ensure the sleeve and crimping die correspond to the hose inner/outer diameter, reinforcement layer, and operating pressure class; also verify the nut/thread dimensions and tail geometry match the hose assembly procedure. When those matches are confirmed, a standard crimping sleeve appropriate for the hose can be used with the ZMW211 fitting.

Can the DKL 90Â° hydraulic end, type ZMW211, light series, carbon steel be used with polyurethane or thermoplastic hose assemblies?

Yes. The DKL 90Â° hydraulic end, type ZMW211, light series, carbon steel can be used with polyurethane or thermoplastic hose assemblies provided the correct crimping sleeve and crimping process for those hose materials are used. The fitting is designed for crimping into hydraulic and industrial hoses using a sleeve suitable for the hose type; ensure the sleeve profile and crimping parameters match the polyurethane or thermoplastic hose manufacturerâs specifications. Also verify compatibility of the metal-metal sealing and the hoseâs pressure, temperature, and chemical resistance ratings with the DKL 24Â°/60Â° cone and the intended application.

Does the DKL 90Â° hydraulic end, type ZMW211, light series, carbon steel require a specific torque for nut tightening?

DKL 90Â° hydraulic end, type ZMW211, light series, carbon steel Format; Based on the provided description (standard hydraulic end fitting type Z, internal metric thread and nut, metal-to-metal sealing, universal cone 24Â°/60Â°, 90Â° angled, lightweight series, for crimping with compatible crimping sleeve, carbon steel, galvanized), a specific nut-tightening torque is not specified. These fittings are intended to be assembled by crimping the hose end with a correctly sized crimping sleeve using the proper crimping machine and die set for the hose type; the crimping process secures the fitting to the hose and is the primary means of attachment, not manual nut torque. However, if the fitting is used in an assembly where the nut must be tightened onto a mating component (e.g., during initial assembly or test), you should follow these guidelines: - Use the torque value recommended by the hose, crimp sleeve, or fitting manufacturer or the equipment OEM. They may publish torque specs for any threaded connections in their assembly procedures. - If no manufacturer torque is available, use good-practice hand-tightening plus a controlled additional quarter- to half-turn with a calibrated torque wrench appropriate for the nut size and thread class, avoiding excessive preload that could deform the metal-to-metal cone sealing surface. - Inspect the metal-to-metal sealing face for correct engagement and absence of damage; leaks or damage indicate improper assembly or excessive torque. - When in doubt, contact the fitting or hose supplier for the exact torque spec or assembly instructions. Summary: No specific torque is given in the descriptionâcrimping is the designed assembly method. For threaded nut tightening, follow manufacturer/OEM torque data; if unavailable, use conservative, controlled tightening and verify seal engagement, or consult the supplier.

DKL 90° hydraulic end, type ZMW211, light series, carbon steel

All products, Fittings for high-pressure hoses/

Additional information

Material	CS – steel (cast iron)

Standard hydraulic end fitting (type Z – with a regular hydraulic “tail” for hose), with internal metric thread and nut, metal-metal sealing, universal cone 24°/60° (DKL), 90° angled, lightweight series. Designed for crimping in hydraulic and industrial hoses using a crimping sleeve suitable for the hose type. Material: carbon steel, galvanized.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
TI-ZMW211-12-04	End fitting 90° G1/2 M12x1.5, hose 1/4", 24/60°, lightweight	6	-	In stock	Enquiry
TI-ZMW211-14-04	End. 90° G1/2 M14x1.5, hose 1/4", 24/60°, light	6	-	In stock	Enquiry
TI-ZMW211-16-04	End fitting 90° G1/2 M16x1.5, hose 1/4", 24/60°, lightweight	6	-	In stock	Enquiry
TI-ZMW211-16-05	End fitting 90° G1/2 M16x1.5, hose 5/16", 24/60°, lightweight	8	-	In stock	Enquiry
TI-ZMW211-16-06	End. 90° G1/2 M16x1.5, hose 3/8", 24/60°, light	10	-	In stock	Enquiry
TI-ZMW211-18-05	End fitting 90° G1/2 M18x1.5, hose 5/16", 24/60°, light	8	-	In stock	Enquiry
TI-ZMW211-18-06	End. 90° G1/2 M18x1.5, hose 3/8", 24/60°, light	10	-	In stock	Enquiry
TI-ZMW211-22-06	End fitting 90° G1/2 M22x1.5, hose 3/8", 24/60°, lightweight	10	-	In stock	Enquiry
TI-ZMW211-22-08	End. 90° G1/2" M22x1.5, hose 1/2", 24/60°, light	12	-	In stock	Enquiry
TI-ZMW211-22X16L-08	End. 90° G1/2" M22x1.5, 16L, hose 1/2", 24/60, lightweight	12	-	In stock	Enquiry
TI-ZMW211-26-10	End fitting 90° G1 M26x1.5, hose 5/8", 24/60°, lightweight	16	-	In stock	Enquiry
TI-ZMW211-27-10	End fitting 90° G1" M27x2, hose 5/8", 24/60°, lightweight	16	-	In stock	Enquiry
TI-ZMW211-27X1,5-10	End fitting 90°, G1" M27x1.5, hose 5/8", 24/60°, lightweight	16	-	In stock	Enquiry
TI-ZMW211-30-12	End. 90° G1 M30x2, hose 3/4", 24/60°, light	20	-	In stock	Enquiry
TI-ZMW211-30-16	End fitting 90° G1 M30x2, hose 1", 24/60°, light	25	-	In stock	Enquiry
TI-ZMW211-36-16	End. 90° G1 M36x2, hose 1", 24/60°, light	25	-	In stock	Enquiry
TI-ZMW211-45-20	End fitting 90° G1/2 M45x2, hose 1.1/4", 24/60°, lightweight	32	-	In stock	Enquiry
TI-ZMW211-52-24	End fitting 90° G1/2 M52x2, hose 1.1/2", 24/60°, lightweight	38	-	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

Standard hydraulic end fitting (type Z – with a regular hydraulic “tail” for hose), with internal metric thread and nut, metal-metal sealing, universal cone 24°/60° (DKL), 90° angled, lightweight series. Designed for crimping in hydraulic and industrial hoses using a crimping sleeve suitable for the hose type. Material: carbon steel, galvanized.
