Is the Metal-rubber gasket for UHP, 1500 bar compatible with quick couplings and external-thread adapters at full 1500 bar working pressure?

Yes. The Metal-rubber gasket for UHP, 1500 bar Format is designed for use in high-pressure installations including quick couplings and adapters with external threads, and its high-strength construction supports a working pressure up to 1500 bar. When installed correctly and paired with compatible coupling and adapter materials and dimensions, it will maintain sealing integrity at the full 1500 bar working pressure. Ensure correct installation torque, surface finish and component compatibility per manufacturer specifications to achieve rated performance.

Can Metal-rubber gasket for UHP, 1500 bar be safely reused after exposure to 1500 bar in quick couplings or external-thread adapters?

No - Metal-rubber gasket for UHP, 1500 bar Format should not be reused after exposure to 1500 bar in quick couplings or external-thread adapters. At such extreme pressures the gasket can undergo permanent deformation, microfractures in the metal core, and damage to the rubber sealing surface that are not visible but compromise sealing integrity. Reuse risks leakage, sudden failure and safety hazards. Replace the Metal-rubber gasket for UHP, 1500 bar Format after any high-pressure service at or near its rated limit, and follow manufacturerâs replacement intervals and inspection procedures.

What inspection or maintenance is required for Metal-rubber gasket for UHP, 1500 bar after use in quick couplings?

For Metal-rubber gasket for UHP, 1500 bar used in quick couplings, perform the following inspection and maintenance after each use: 1. Visual inspection - Check the gasket surface for nicks, cuts, abrasions, extrusion marks, deformation or flattening of the metal and rubber parts. - Look for cracks, delamination, swelling, hardening or soft spots in the rubber and for corrosion, pitting or discoloration of the metal ring. - Ensure the gasket profile and seating faces remain symmetrical and free of embedded particles. 2. Dimensional and seating check - Verify the gasket retains correct outer and inner diameters and thickness; excessive permanent compression or uneven thickness indicates replacement. - Confirm the sealing face contacts evenly; any localized gaps, buckling or uneven compression are signs of failure. 3. Cleanliness - Clean with a lint-free cloth and a compatible solvent (e.g., isopropyl alcohol) to remove hydraulic fluid, dirt and debris. Do not use aggressive chemicals that swell or degrade the rubber. - Remove trapped particles from grooves and seatings to avoid damage on next use. 4. Functional checks - Check for loss of elasticity in the rubber and loss of spring-back after compression. - If available, perform a low-pressure leak test after reassembly to confirm proper sealing before returning to service. 5. Wear limits and replacement criteria - Replace gasket if any mechanical damage, visible cracks, extrusion, significant corrosion, permanent deformation, or loss of sealing surface integrity is present. - Replace after any overpressure event, coupling misalignment or if the gasket has been reused beyond the manufacturerâs recommended number of cycles. - Replace if rubber shows chemical attack (swelling, softening) or if metal ring is bent or severely worn. 6. Storage and handling after inspection - Store clean gaskets flat in a dry, dark environment away from oils, solvents and UV. Avoid stacking heavy items on top. - Handle by non-abrasive tools; avoid dropping or stretching the gasket. 7. Documentation - Record inspection date, condition, any defects and replacement action. Track service life and number of cycles. Safety note: Always depressurize and follow safe disconnection procedures before removing or inspecting Metal-rubber gasket for UHP, 1500 bar. When in doubt, consult the gasket manufacturerâs specific maintenance guidelines.

Metal-rubber gasket for UHP, 1500 bar

All products, UHP adapters and accessories/

Additional information

Metal-rubber gasket for use in high-pressure installations (for quick couplings, adapters with external threads). High-strength version. Working pressure: up to 1500 bar.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Price	Quantity	Actions	Catalogue
CJ-HP-199500083	Metal-rubber gasket 1/4", 1500 bar	-	-	In stock	0 zł		Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

Metal-rubber gasket for use in high-pressure installations (for quick couplings, adapters with external threads). High-strength version. Working pressure: up to 1500 bar.
