Is the Spray gun with 0.7 mm nozzle, 269 series suitable for use at 6 bar continuous operating pressure?

Yes. The Spray gun with 0.7 mm nozzle, 269 series is specified for an operating pressure range of 1 to 6 bar and a maximum pressure of 10 bar. Continuous use at 6 bar falls within its rated operating range. At 6 bar the nominal flow rate with the valve fully open is 0.33 l/min. Ensure operating temperature remains within +5Â°C to +50Â°C and use only low-viscosity, non-explosive fluids as intended.

Can Spray gun with 0.7 mm nozzle, 269 series be used for spraying non-explosive low-viscosity liquids at temperatures down to +5Â°C?

Yes. The Spray gun with 0.7 mm nozzle, 269 series is specified for low-viscosity, non-explosive fluids and has an operating temperature range from +5Â°C to +50Â°C, so it can be used for spraying non-explosive low-viscosity liquids at temperatures down to +5Â°C. Ensure operating pressure (1â6 bar, max 10 bar) and nominal flow (0.33 l/min at 6 bar) match your application and follow all safety and handling instructions for the fluid.

Can the Spray gun with 0.7 mm nozzle, 269 series achieve a consistent conical spray pattern at various lever pressure settings?

Yes. The Spray gun with 0.7 mm nozzle, 269 series can produce a consistent conical spray pattern (~40Â°) across different lever pressure settings, because the tool is standardly fitted with a nozzle containing a swirling insert specifically designed to form a stable conical spray. Flow is regulated by lever pressure within the deviceâs operating range (1â6 bar), so varying the lever changes flow rate while the swirling insert maintains the spray geometry. Limits and practical notes: - Best pattern stability will be within the recommended operating pressure range (1â6 bar); at very low pressures near 1 bar pattern uniformity can diminish, and at pressures approaching the maximum (above recommended 6 bar, up to 10 bar max) spray characteristics may alter or cause wear. - Nominal flow with the valve fully open is 0.33 l/min at 6 bar; intermediate lever positions will reduce flow but the conical shape should remain approximately 40Â° thanks to the insert and 0.7 mm nozzle diameter. - For consistent results use low-viscosity, non-explosive fluids and operate within the specified temperature range (+5Â°C to +50Â°C).

Spray gun with 0.7 mm nozzle, 269 series

All products, Special air guns/

Additional information

Spray gun for low-viscosity liquids and non-explosive fluids. Standardly equipped with a nozzle featuring a swirling insert. Conical spray pattern – approx. 40°. Flow regulation by lever pressure. Material: forged aluminum. Nozzle diameter: 0.7 mm. Operating pressure: 1 to 6 bar. Maximum pressure: 10 bar. Nominal flow rate with fully open valve: 0.33 l/min (6 bar). Operating temperature: from +5°C to +50°C.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Price	Quantity	Actions	Catalogue
EW-26935	Spray gun with a 0.7 mm nozzle, end 6 mm	-	10	In stock	0 zł		Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

Spray gun for low-viscosity liquids and non-explosive fluids. Standardly equipped with a nozzle featuring a swirling insert. Conical spray pattern – approx. 40°. Flow regulation by lever pressure. Material: forged aluminum. Nozzle diameter: 0.7 mm. Operating pressure: 1 to 6 bar. Maximum pressure: 10 bar. Nominal flow rate with fully open valve: 0.33 l/min (6 bar). Operating temperature: from +5°C to +50°C.
