Is the Collet for hydraulic hoses 1SN, 2SN, 2SC, zinc-nickel carbon steel, type ZF12T corrosion-resistant for marine environments?

Yes. Collet for hydraulic hoses 1SN, 2SN, 2SC, zinc-nickel carbon steel, type ZF12T is designed to be corrosion-resistant for marine environments. The zincânickel plating (6â10 Âµm) provides very high corrosion resistance . tested up to 720 hours without corrosion in a salt spray chamber . which indicates strong protection against seawater and salt-laden atmospheres. Material is carbon steel with zincânickel coating, and no machining is required for installation. For long-term marine use, consider system design (galvanic compatibility with other metals), regular inspection and maintenance, and any additional protective measures if exposure is extreme or continuous.

Does the Collet for hydraulic hoses 1SN, 2SN, 2SC, zinc-nickel carbon steel, type ZF12T require special tools for installation?

Collet for hydraulic hoses 1SN, 2SN, 2SC, zinc-nickel carbon steel, type ZF12T: No special tools are required for installation. The ZF12T clamp sleeve is designed for rubber hydraulic hoses type 1SN(R1AT), 2SN(R2AT) or 2SC and specifies âinstallation - no machining required,â meaning it can be fitted without special machining or dedicated installation tools. Standard workshop tools for hose assembly should suffice; surface is zinc-nickel coated (6â10 Âµm) on carbon steel for high corrosion resistance.

Collet for hydraulic hoses 1SN, 2SN, 2SC, zinc-nickel carbon steel, type ZF12T

Q: Can the Collet for hydraulic hoses 1SN, 2SN, 2SC, zinc-nickel carbon steel, type ZF12T be reused after removal?

Can the Collet for hydraulic hoses 1SN, 2SN, 2SC, zinc-nickel carbon steel, type ZF12T be reused after removal? Generally no. reuse is not recommended. Reasoning: The Collet for hydraulic hoses 1SN, 2SN, 2SC, zinc-nickel carbon steel, type ZF12T is a clamp sleeve designed for secure, interference-fit installation on rubber hydraulic hoses without machining. During assembly the collet plastically deforms and forms a mechanical seal around the hose and fitting. Removal typically damages the colletâs shape, reduces its clamping integrity and may compromise the zinc-nickel coating. Because the componentâs function depends on precise geometry and surface condition to maintain pressure integrity and corrosion resistance (zincânickel layer 6â10 Âµm, up to 720 h salt spray protection), a reused collet risks leaks, blowouts or premature corrosion. When reuse might be considered: Only if the collet shows no visible deformation, cracks, corrosion or coating damage and full dimensional integrity can be verified by proper inspection. which is uncommon and impractical in normal workshop conditions. For safety-critical hydraulic systems, replacement with a new Collet for hydraulic hoses 1SN, 2SN, 2SC, zinc-nickel carbon steel, type ZF12T is the recommended practice.

All products, Fittings for high-pressure hoses/

Additional information

Material	CS – steel (cast iron)

ZF12T clamp sleeve for rubber hydraulic hoses type 1SN(R1AT), 2SN(R2AT) or 2SC. Installation – no machining required. Surface coated with zinc-nickel with a layer thickness of 6-10 µm, which exhibits very high corrosion resistance (up to 720 hours without corrosion in a salt spray chamber). Diameter D1 [mm] – outer diameter. Material: carbon steel, zinc-nickel.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
TI-ZF12T-03-CN	Sleeve for hose 1SN/2SN/2SC 3/16", Zn-Ni	5	-	In stock	Enquiry
TI-ZF12T-04-CN	Sleeve for hose 1SN/2SN/2SC 1/4", Zn-Ni	6	-	In stock	Enquiry
TI-ZF12T-05-CN	Sleeve for hose 1SN/2SN/2SC 5/16", Zn-Ni	8	-	In stock	Enquiry
TI-ZF12T-06-CN	Sleeve for hose 1SN/2SN/2SC 3/8", Zn-Ni	10	-	In stock	Enquiry
TI-ZF12T-08-CN	Sleeve for hose 1SN/2SN/2SC 1/2", Zn-Ni	12	-	In stock	Enquiry
TI-ZF12T-10-CN	Sleeve for hose 1SN/2SN/2SC 5/8", Zn-Ni	16	-	In stock	Enquiry
TI-ZF12T-12-CN	Sleeve for hose 1SN/2SN/2SC 3/4", Zn-Ni	20	-	In stock	Enquiry
TI-ZF12T-16-CN	Sleeve for hose 1SN/2SN/2SC 1", Zn-Ni	25	-	In stock	Enquiry
TI-ZF12T-20-CN	Sleeve for hose 1SN/2SN/2SC 1.1/4", Zn-Ni	32	-	In stock	Enquiry
TI-ZF12T-24-CN	Sleeve for hose 1SN/2SN/2SC 1.1/2", Zn-Ni	38	-	In stock	Enquiry
TI-ZF12T-32-CN	Sleeve for hose 1SN/2SN/2SC 2", Zn-Ni	50	-	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

ZF12T clamp sleeve for rubber hydraulic hoses type 1SN(R1AT), 2SN(R2AT) or 2SC. Installation – no machining required. Surface coated with zinc-nickel with a layer thickness of 6-10 µm, which exhibits very high corrosion resistance (up to 720 hours without corrosion in a salt spray chamber). Diameter D1 [mm] – outer diameter. Material: carbon steel, zinc-nickel.
