Is the DKR 90Â° hydraulic end, type ZBW210, carbon steel, Y compatible with standard BSP-threaded hoses and crimping sleeves for industrial hydraulic use?

Yes. The DKR 90Â° hydraulic end, type ZBW210, carbon steel, Y is compatible with standard BSP-threaded hoses and crimping sleeves for industrial hydraulic use. The description states it has an internal BSP thread with nut and a 60Â° sealing cone (DKR), and it is specifically designed for crimping into hydraulic and industrial hoses using a crimping sleeve appropriate for the hose type. Made of carbon steel and galvanized, it meets typical material and sealing/interface requirements for BSP-threaded hose assemblies when the correct sleeve and hose are used. Ensure you match the hose inner diameter, sleeve profile, and crimping parameters to the manufacturerâs recommendations and verify thread size and sealing cone compatibility before assembly.

Can the DKR 90Â° hydraulic end, type ZBW210, carbon steel, Y be used with hoses requiring a 60Â° sealing cone and internal BSP threads?

Yes. The DKR 90Â° hydraulic end, type ZBW210, carbon steel, Y Format is designed for use with hoses requiring a 60Â° sealing cone and internal BSP threads. It features a 60Â° DKR sealing cone, internal BSP thread with nut, a regular hydraulic tail (type Z) for crimping, and is intended for crimping with a sleeve matched to the hose type. Material and finish (carbon steel, galvanized) are appropriate for typical hydraulic/industrial applications. Ensure you use the correct crimping sleeve and follow hose/manufacturer specifications for pressure rating and compatibility.

Does the DKR 90Â° hydraulic end, type ZBW210, carbon steel, Y require specific crimp sleeve dimensions or standards?

DKR 90Â° hydraulic end, type ZBW210, carbon steel, Y does not specify unique crimp sleeve dimensions or a proprietary standard in the provided description. It is designed for crimping with a crimping sleeve appropriate for the hose type being used. Practical implications: - Use the crimp sleeve size and profile recommended by the hose manufacturer for the specific hose series and nominal size to ensure proper crimp diameter, compression profile and mechanical retention. - Confirm compatibility with a 90Â° angled fitting and the internal BSP thread/nut assemblyâsome hose/sleeve combinations require specific insertion depth or sleeve length to accommodate the fitting tail. - Ensure the sleeve material and plating are suitable for carbon steel, galvanized fitting to avoid galvanic corrosion (typically steel sleeves, possibly plated). - Follow crimping machine specifications (force, jaw type, and crimping profile) from the hose supplier to meet pressure and safety ratings. - Verify sealing: the DKR 60Â° cone seating surface requires correct hose end positioning so the cone seats properly after crimping. - If project or cert requirements apply, use sleeves and processes that meet applicable standards (e.g., EN 853/EN 857, SAE J516/J517, ISO 12151 for hose fittings) as specified by the hose and system designer. If you need exact sleeve dimensions (length, outer diameter after crimp, profile), provide the hose make/model and nominal size or consult the hose manufacturer's crimp sleeve chart and the hose assembly specification for precise crimping parameters.

Fitting hydraulic DKR 90°, type ZBW210, carbon steel, Y

All products, Fittings for high-pressure hoses/

Additional information

Material	CS – steel (cast iron)

Standard hydraulic fitting (type Z – with an ordinary hydraulic “tail” for the hose), with BSP female thread with a nut, 60° sealing cone (DKR), angled 90°. Intended for crimping onto hydraulic and industrial hoses using a ferrule suitable for the hose type. Material: carbon steel, galvanized.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
TI-ZBW210-06-05-Y	Fitting 90° 3/8" BSP female, hose 5/16", 60° cone	8	-	In stock	Enquiry
TI-ZBW210-06-06-Y	Fitting 90° 3/8" BSP female, hose 3/8", 60° cone	10	-	In stock	Enquiry
TI-ZBW210-08-05-Y	Fitting 90° 1/2" BSP female,hose 5/16", 60° cone	8	-	In stock	Enquiry
TI-ZBW210-08-06-Y	Fitting 90° 1/2" BSP female, hose 3/8", 60° cone	10	-	In stock	Enquiry
TI-ZBW210-08-08-Y	Fitting 90° 1/2" BSP female, hose 1/2", 60° cone	12	-	In stock	Enquiry
TI-ZBW210-12-08-Y	Fitting 90° 3/4" BSP female, hose 1/2", 60° cone	12	-	In stock	Enquiry
TI-ZBW210-12-10-Y	Fitting 90° 3/4" BSP female, hose 5/8", 60° cone	16	-	In stock	Enquiry
TI-ZBW210-12-12-Y	Fitting 90° 3/4" BSP female, hose 3/4", 60° cone	20	-	In stock	Enquiry
TI-ZBW210-20-16-Y	Fitting 90° 1.1/4" BSP female hose 1", 60° cone	25	-	In stock	Enquiry
TI-ZBW210-20-20-Y	Fitting 90° 1.1/4" BSP female, hose 1.1/4", 60° cone	32	-	In stock	Enquiry
TI-ZBW210-24-20-Y	Fitting 90° 1.1/2" BSP female, hose 1.1/4", 60° cone	32	-	In stock	Enquiry
TI-ZBW210-24-24-Y	Fitting 90° 1.1/2" BSP female, hose 1.1/2", 60° cone	38	-	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

Standard hydraulic fitting (type Z – with an ordinary hydraulic “tail” for the hose), with BSP female thread with a nut, 60° sealing cone (DKR), angled 90°. Intended for crimping onto hydraulic and industrial hoses using a ferrule suitable for the hose type. Material: carbon steel, galvanized.
