Is the SAE 6000 45Â° flange end, type ZSK312, heavy series, carbon steel, zinc-nickel compatible with standard hydraulic crimping sleeves for industrial hoses?

Yes. The SAE 6000 45Â° flange end, type ZSK312, heavy series, carbon steel, zinc-nickel is designed specifically for crimping into hydraulic and industrial hoses using a crimping sleeve that matches the hose type. Its heavy-series flange geometry and 45Â° angle are compatible with standard industrial crimping processes, and the carbon steel body with a 6â10 Âµm zincânickel coating provides robust corrosion resistance suitable for demanding environments. Ensure you use a crimping sleeve sized and shaped for the specific hose construction and follow the hose and crimping tool manufacturerâs specifications (crimp diameter, press force, die profile) to achieve a proper, leakâfree, and safe assembly.

Can the SAE 6000 45Â° flange end, type ZSK312, heavy series, carbon steel, zinc-nickel withstand high-salinity environments without additional coating?

Yes - the SAE 6000 45Â° flange end, type ZSK312, heavy series, carbon steel, zinc-nickel can withstand high-salinity environments without additional coating for many applications. Its zincânickel surface layer (6â10 Âµm) offers very high corrosion resistance - tested up to 720 hours salt spray without corrosion - which substantially delays galvanic and pitting attack in marine or saline conditions. Caveats: longevity depends on exposure severity (continuous seawater immersion, splash, abrasion, or galvanic coupling may shorten life). For critical, long-term, or continuously submerged installations, or where mechanical damage is likely, additional protection (thicker coatings, sacrificial anodes, or stainless alternatives) is recommended.

What crimping sleeve dimensions are recommended for SAE 6000 45Â° flange end, type ZSK312, heavy series, carbon steel, zinc-nickel?

For SAE 6000 45Â° flange end, type ZSK312, heavy series, carbon steel, zinc-nickel, use a crimping sleeve specified for SAE 6000 (SFL) heavy-series fittings matched to the hose inner diameter and reinforcement type. Recommended sleeve dimensions (typical guidance. confirm with hose manufacturer): - Sleeve type: heavy-series crimping sleeve compatible with SAE 6000 (SFL) 45Â° flange fittings. - Sleeve length: typically 1.1â1.4 Ã hose outer diameter (OD). - Sleeve internal diameter before crimp: match hose outer diameter (Â±0.1 mm). - Final crimp diameter: reduce sleeve OD to achieve a crimp height resulting in sleeve compression of ~10â15% of hose wall (manufacturer charts). - Crimp profile: multi-segment or hex/hexagonal ring profile for heavy-series SAE 6000 to ensure uniform compression. - Wall thickness: proportioned to sleeve diameter and material strengthâcommonly 2.5â4.5 mm for SAE 6000 heavy sleeves in carbon steel. - Surface: zinc-nickel coating (6â10 Âµm) as specified for corrosion resistance. Important: exact sleeve length, starting bore, and final crimp diameters vary by hose construction (braided vs. spiral), hose OD, and manufacturer. Always use the crimping sleeve dimensions and crimping dies recommended by the hose and fitting manufacturers or the assembly machine supplier for SAE 6000 45Â° flange end, type ZSK312, heavy series, carbon steel, zinc-nickel to ensure safe, leak-free assemblies.

SAE 6000 45° flange end, type ZSK312, heavy series, carbon steel, zinc-nickel

All products, Fittings for high-pressure hoses/

Additional information

Material	CS – steel (cast iron)
Standard length [m]	10, 2

SAE 6000 flange end (SFL), 45° angled, heavy series. Designed for crimping in hydraulic and industrial hoses using a crimping sleeve suitable for the hose type. Surface coated with zinc-nickel with a layer thickness of 6-10 µm, which exhibits very high corrosion resistance (up to 720 hours without corrosion in a salt spray chamber). Material: carbon steel, zinc-nickel.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
TI-ZSK312-08-08-CN	End fitting 45° SAE 1/2", hose 1/2", heavy, Zn-Ni	12	-	In stock	Enquiry
TI-ZSK312-12-08-CN	End fitting 45° SAE 3/4", hose 1/2", heavy, Zn-Ni	12	-	In stock	Enquiry
TI-ZSK312-12-10-CN	End fitting 45° SAE 3/4", hose 5/8", heavy, Zn-Ni	16	-	In stock	Enquiry
TI-ZSK312-12-12-CN	End fitting 45° SAE 3/4", hose 3/4", heavy, Zn-Ni	20	-	In stock	Enquiry
TI-ZSK312-16-12-CN	End fitting 45° SAE 1", hose 3/4", heavy, Zn-Ni	20	-	In stock	Enquiry
TI-ZSK312-16-16-CN	End fitting 45° SAE 1", hose 1", heavy, Zn-Ni	25	-	In stock	Enquiry
TI-ZSK312-20-16-CN	End fitting 45° SAE 1.1/4", hose 1", heavy, Zn-Ni	25	-	In stock	Enquiry
TI-ZSK312-20-20-CN	End fitting 45° SAE 1.1/4", hose 1.1/4", heavy, Zn-Ni	32	-	In stock	Enquiry
TI-ZSK312-24-20-CN	End fitting 45° SAE 1.1/2", hose 1.1/4", heavy, Zn-Ni	32	-	In stock	Enquiry
TI-ZSK312-24-24-CN	End fitting 45° SAE 1.1/2", hose 1.1/2", heavy, Zn-Ni	38	-	In stock	Enquiry
TI-ZSK312-32-24-CN	End fitting 45° SAE 2", hose 1.1/2", heavy, Zn-Ni	38	-	In stock	Enquiry
TI-ZSK312-32-32-CN	End fitting 45° SAE 2", hose 2", heavy, Zn-Ni	50	-	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

SAE 6000 flange end (SFL), 45° angled, heavy series. Designed for crimping in hydraulic and industrial hoses using a crimping sleeve suitable for the hose type. Surface coated with zinc-nickel with a layer thickness of 6-10 µm, which exhibits very high corrosion resistance (up to 720 hours without corrosion in a salt spray chamber). Material: carbon steel, zinc-nickel.
