Does the DKOR 90Â° hydraulic end, type ZBW220, carbon steel, zinc-nickel require a specific crimping sleeve size or profile for proper hose assembly?

Yes. The DKOR 90Â° hydraulic end, type ZBW220, carbon steel, zinc-nickel requires a crimping sleeve matched to the hose type and size. It is designed for crimping into hydraulic and industrial hoses, so you must use a sleeve profile and diameter specified by the hose manufacturer that correspond to the ZBW220 tail geometry and hose inner/outer dimensions. Using the correct sleeve ensures proper compression of the hose cover and reinforcement onto the DKOR 60Â° cone sealing surface and provides required swaging depth, mechanical retention and leak-free performance. Always follow the hose and sleeve supplierâs crimping charts (tooling and die set) and the hose assembly procedure; do not substitute a generic sleeve size or profile without verification.

Can DKOR 90Â° hydraulic end, type ZBW220, carbon steel, zinc-nickel be used with hoses operating above 350 bar without changing sleeve specifications?

No - DKOR 90Â° hydraulic end, type ZBW220, carbon steel, zinc-nickel cannot be assumed safe for hoses operating above 350 bar without changing sleeve specifications. The description states it is designed for crimping with a sleeve suitable for the hose type, but gives no sleeve pressure rating. For pressures >350 bar you must verify the crimp sleeve and assembly specification (material, dimensions, crimp profile and certified pressure rating) match the hoseâs maximum working and burst pressures and meet applicable standards. Also confirm crimping tool, O-ring specification and thread/nut engagement are rated for >350 bar. Without explicit sleeve and assembly certification for that pressure, do not use.

Is the DKOR 90Â° hydraulic end, type ZBW220, carbon steel, zinc-nickel compatible with metric BSP hose fittings?

Yes. The DKOR 90Â° hydraulic end, type ZBW220, carbon steel, zinc-nickel is compatible with metric BSP hose fittings that use an internal BSP thread and nut and seal via an Oâring on a 60Â° cone (DKOR). The product description specifies an internal BSP thread and nut with Oâring sealing on a 60Â° cone and is designed for crimping onto hydraulic and industrial hoses using a suitable crimping sleeve, so it will mate correctly with metric BSP male fittings of the matching thread size and 60Â° cone sealing geometry. Ensure the male fittingâs BSP thread size and cone angle match the ZBW220 specification and use the correct crimp sleeve for your hose type for secure, leakâfree assembly.

DKOR 90° hydraulic end, type ZBW220, carbon steel, zinc-nickel

All products, Fittings for high-pressure hoses/

Additional information

Material	CS – steel (cast iron)

Standard hydraulic end (type Z – with a regular hydraulic “tail” for hose), with internal BSP thread and nut, sealing with an O-ring on a 60° cone (DKOR), 90° angled. Designed for crimping in hydraulic and industrial hoses using a crimping sleeve suitable for the hose type. Surface coated with zinc-nickel with a layer thickness of 6-10 µm, characterized by very high corrosion resistance (up to 720 hours without corrosion in a salt spray chamber). Material: carbon steel, zinc-nickel.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
TI-ZBW220-04-04-CN	End fitting 90° G 1/4" BSP, hose 1/4", cone 60°, o-ring, Zn-Ni	6	-	In stock	Enquiry
TI-ZBW220-06-06-CN	End fitting 90° GW 3/8" BSP, hose 3/8", cone 60°, o-ring, Zn-Ni	10	-	In stock	Enquiry
TI-ZBW220-08-08-CN	End fitting 90° GW 1/2" BSP, hose 1/2", cone 60°, o-ring, Zn-Ni	12	-	In stock	Enquiry
TI-ZBW220-10-10-CN	End fitting 90° G 5/8" BSP, hose 5/8", cone 60°, o-ring, Zn-Ni	16	-	In stock	Enquiry
TI-ZBW220-12-12-CN	End fitting 90° GW 3/4" BSP, hose 3/4", cone 60°, o-ring, Zn-Ni	20	-	In stock	Enquiry
TI-ZBW220-16-16-CN	End fitting 90° GW 1" BSP, hose 1", cone 60°, o-ring, Zn-Ni	25	-	In stock	Enquiry
TI-ZBW220-20-16-CN	End fitting 90° GW 1.1/4" BSP, hose 1", cone 60°, o-ring, Zn-Ni	25	-	In stock	Enquiry
TI-ZBW220-20-20-CN	Elbow 90° G 1.1/4" BSP, hose 1.1/4", cone 60°, o-ring, Zn-Ni	32	-	In stock	Enquiry
TI-ZBW220-24-20-CN	Elbow 90° G 1.1/2" BSP, hose 1.1/4", cone 60°, o-ring, Zn-Ni	32	-	In stock	Enquiry
TI-ZBW220-24-24-CN	Elbow 90° G 1.1/2" BSP, hose 1.1/2", cone 60°, o-ring, Zn-Ni	38	-	In stock	Enquiry
TI-ZBW220-32-32-CN	End fitting 90° GW 2" BSP, hose 2", cone 60°, o-ring, Zn-Ni	50	-	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

Standard hydraulic end (type Z – with a regular hydraulic “tail” for hose), with internal BSP thread and nut, sealing with an O-ring on a 60° cone (DKOR), 90° angled. Designed for crimping in hydraulic and industrial hoses using a crimping sleeve suitable for the hose type. Surface coated with zinc-nickel with a layer thickness of 6-10 µm, characterized by very high corrosion resistance (up to 720 hours without corrosion in a salt spray chamber). Material: carbon steel, zinc-nickel.
