Is the Plug tee "L" with BSPT male thread, type R 39 NSF safe for use with potable hot and cold drinking water up to 150Â°C and compliant with NSF/ANSI 51 and 61?

Yes. The Plug tee "L" with BSPT male thread, type R 39 NSF is designed for food-industry use (including cold and hot drinking water), has no plastic components, uses nickel-plated brass construction with Viton seals approved for food contact by the FDA, and is rated to operate from -20Â°C to +150Â°C. It meets NSF/ANSI 51 and NSF/ANSI 61 standards and is specified for potable water applications. Therefore it is suitable and compliant for use with potable hot and cold drinking water up to 150Â°C.

Can the Plug tee "L" with BSPT male thread, type R 39 NSF be used in chemical and pharmaceutical applications requiring high detergent resistance?

Yes. The Plug tee "L" with BSPT male thread, type R 39 NSF is suitable for chemical and pharmaceutical applications requiring high detergent resistance. It has no plastic parts, is nickel-plated brass, uses Viton seals (FDA-approved for food contact) and is explicitly described as offering high resistance to detergents and other chemicals. Its operating range (-20Â°C to +150Â°C), working pressure (16 bar), and NSF certifications (NSF/ANSI 51 and 61) further support suitability for food, chemical, pharmaceutical, electronic and medical uses. Ensure compatibility with specific chemicals in your process by checking Viton and nickel-plated brass chemical resistance charts for any aggressive agents.

Does the Plug tee "L" with BSPT male thread, type R 39 NSF contain any plastic components that could affect food safety?

No. the Plug tee "L" with BSPT male thread, type R 39 NSF does not contain any plastic components that could affect food safety. It is made of nickel-plated brass (nickel coating applied by a special chemical process) with Viton seals; Viton is FDA-approved for food contact and offers high resistance to detergents and chemicals. The product is designed for the food industry and meets NSF/ANSI 51 and NSF/ANSI 61 standards.

Plug tee “L” with BSPT male thread, type R 39 NSF

All products, Push-in fittings/

Additional information

Material	B – brass (bronze)

BSPT threaded elbow with external tapered thread, series F type R 39 NSF. Designed for the food industry (e.g., for cold or hot drinking water). No plastic components, nickel-coated through a special chemical process, and Viton seals provide high resistance to detergents and other chemicals. Also suitable for various applications in the chemical, pharmaceutical, electronic industries, and in medicine. Operating temperature: from -20°C to +150°C. Working pressure: 16 bar. Vacuum: 0.99 bar. Material: nickel-plated brass. Seal: Viton (approved for food contact by the FDA). Standards: NSF/ANSI 51, NSF/ANSI 61.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
MW-2F39C02	Angle connector (elbow) R39 NSF hose 4 mm, GZ BSPT 1/8"	-	16	In stock	Enquiry
MW-2F39C08	Angle connector (elbow) R39 NSF hose 6 mm, GZ BSPT 1/8"	-	16	In stock	Enquiry
MW-2F39C09	Angle connector (elbow) R39 NSF hose 6 mm, GZ BSPT 1/4"	-	16	In stock	Enquiry
MW-2F39C10	Angle connector (elbow) R39 NSF hose 8 mm, GZ BSPT 1/8"	-	16	In stock	Enquiry
MW-2F39C11	Angle connector (elbow) R39 NSF hose 8 mm, GZ BSPT 1/4"	-	16	In stock	Enquiry
MW-2F39C12	Angle connector (elbow) R39 NSF hose 8 mm, GZ BSPT 3/8"	-	16	In stock	Enquiry
MW-2F39C13	Angle connector (elbow) R39 NSF hose 10 mm, GZ BSPT 1/4"	-	16	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

BSPT threaded elbow with external tapered thread, series F type R 39 NSF. Designed for the food industry (e.g., for cold or hot drinking water). No plastic components, nickel-coated through a special chemical process, and Viton seals provide high resistance to detergents and other chemicals. Also suitable for various applications in the chemical, pharmaceutical, electronic industries, and in medicine. Operating temperature: from -20°C to +150°C. Working pressure: 16 bar. Vacuum: 0.99 bar. Material: nickel-plated brass. Seal: Viton (approved for food contact by the FDA). Standards: NSF/ANSI 51, NSF/ANSI 61.
