Is the STECKO plug connector for use in hydraulic systems made of automatic steel and galvanized, with NBR O-ring and Teflon back-up ring, compatible with mine hydraulic fluids?

To determine compatibility of the STECKO plug connector (automatic steel, galvanized; sealing: NBR O-ring, Teflon back-up ring) with your hydraulic fluids, consider these points: 1. NBR (nitrile rubber) is generally resistant to mineral oils and petroleum-based hydraulic fluids (e.g., ISO HM/HLP types). It performs well with oils containing anti-wear additives but has limited resistance to phosphate esters, water-glycol fluids, and some synthetic esters. NBR also swells or degrades with many aggressive solvents, ketones, and strong acids/alkalis. 2. Teflon (PTFE) back-up rings are chemically very resistant and provide excellent support for the O-ring under high pressure and extrusion-prone gaps; PTFE tolerates almost all hydraulic fluids, high temperatures, and aggressive chemicals. 3. Automatic steel, galvanized construction is suitable for mining hydraulic systems; steel provides strength, and galvanization offers corrosion protection, though it can be attacked by strongly acidic or alkaline fluids and some chloride-rich environments. Compatibility also depends on fluid contamination (water, chlorides) and operating environment. Conclusion: STECKO plug connector is compatible with standard mineral oilâbased hydraulic fluids used in mining. If your fluids are synthetic esters, phosphate esters (e.g., Skydrol), water-glycol, polyalkylene glycols, or contain aggressive solvents/chemicals, verify compatibility: NBR may degrade with those and a different elastomer (e.g., FKM, EPDM) may be required. Provide the exact fluid type and manufacturer compatibility data for a definitive answer.

Can the STECKO plug connector in automatic steel with NBR O-ring and Teflon back-up ring withstand high-pressure mining hydraulic systems?

The STECKO plug connector in automatic steel (galvanized) with an NBR O-ring and Teflon back-up ring is suitable for many mining hydraulic applications, but suitability for high-pressure systems depends on specific pressure ratings and operating conditions. Automatic steel body and galvanization give good mechanical strength and corrosion resistance; NBR offers reliable sealing for oils and fuels within typical temperature ranges, while the Teflon back-up ring prevents O-ring extrusion at elevated pressures. If system pressure stays within the connectorâs specified maximum working pressure and temperature limits, and installation follows manufacturer torque and cleanliness guidelines, the STECKO plug connector can withstand high-pressure mining hydraulics. Confirm exact pressure and temperature ratings, compatibility with hydraulic fluid, and relevant mining certifications before use.

Does the STECKO plug connector in automatic steel with NBR O-ring resist corrosion in mining environments?

The STECKO plug connector, automatic steel format, galvanized, with NBR O-ring and Teflon back-up ring offers a reasonable level of corrosion resistance for mining hydraulic environments but with important limitations. - Corrosion resistance (steel + galvanization): The automatic steel body with galvanization provides a basic protective zinc coating that helps resist general corrosion and is suitable for many industrial and mining applications. However, galvanization can wear over time under abrasive, highly humid, or chemically aggressive mining conditions (acidic/alkaline waters, chloride-rich sprays). In such environments, the zinc layer may degrade, exposing steel to corrosion. - Sealing materials: NBR O-ring gives good resistance to oils, hydraulic fluids and many common industrial chemicals and maintains sealing under pressure and vibration typical in mining. NBR is not highly resistant to ozone, certain solvents, high temperatures (>100â120Â°C) or aggressive chemicals; prolonged exposure to such agents can accelerate leakage and material degradation. The Teflon (PTFE) back-up ring adds chemical inertness and supports the O-ring against extrusion, improving durability and sealing performance. - Overall suitability for mining: For standard hydraulic circuits in mining (oil-based fluids, moderate temperatures, typical humidity), the STECKO plug connector should perform reliably for corrosion and sealing. In harsher mining conditionsâhigh salinity, acidic waters, strong chemical exposure, extreme temperatures, heavy abrasion, or prolonged immersionâadditional corrosion protection (stainless steel construction, thicker/coated plating, or sacrificial/anodic protection) or alternative elastomers (e.g., FKM/Viton for higher chemical/temperature resistance) may be advisable. Recommendation: Verify the specific mine environment (salinity, pH, temperature, abrasive wear, chemical exposure) and maintenance intervals. If conditions are aggressive, consider connectors in stainless steel or with enhanced coatings and select a sealing material better suited than NBR.

Fitting plug-in STECKO, free-cutting steel

All products, Fittings for high-pressure hoses/

Additional information

Material	CS – steel (cast iron)
Standard length [m]	10

Fitting plug-in systemu STECKO for use in hydraulic systems for mining. Material: free-cutting steel, galvanized. sealing: NBR (O-ring), teflon (ring oporowy).

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
TI-GST-5-21A	Fitting plug-in STECKO 4/6	-	640	In stock	Enquiry
TI-GST-5-21B	Fitting plug-in STECKO 8/10	-	530	In stock	Enquiry
TI-GST-5-21C	Fitting plug-in STECKO 12	-	500	In stock	Enquiry
TI-GST-5-21E	Fitting plug-in STECKO 20	-	450	In stock	Enquiry
TI-GST-5-21F	Fitting plug-in STECKO 25	-	400	In stock	Enquiry
TI-GST-5-21G	Fitting plug-in STECKO 32	-	300	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

Fitting plug-in systemu STECKO for use in hydraulic systems for mining. Material: free-cutting steel, galvanized. sealing: NBR (O-ring), teflon (ring oporowy).
