Can the 45Â° NON SKIVE SAE 3000 flange end, light series, carbon steel, type NSK311 be crimped onto 4SP/4SH/R13/R15 hoses using a TI-N sleeve without cutting the hose rubber?

Yes. The 45Â° NON SKIVE SAE 3000 flange end, light series, carbon steel, type NSK311 is specifically designed for crimping onto 4SP/4SH/R13/R15 hoses using a TI-N crimping sleeve and can be installed without cutting the hose rubber. The product description states compatibility with those hose types, uses a TI-N sleeve for crimping, and explicitly lists installation âwithout cutting the hose rubber,â confirming correct application and installation method.

Does the 45Â° NON SKIVE SAE 3000 flange end, light series, carbon steel, type NSK311 require special crimping settings with TI-N sleeves?

Noâ the 45Â° NON SKIVE SAE 3000 flange end, light series, carbon steel, type NSK311 does not require special crimping settings when used with TIâN sleeves beyond the standard crimping procedure specified for TIâN sleeves and the compatible hose types (4SP, 4SH, R13, R15). Key points: - The design (nonâskive, lightweight) and the installation note âwithout cutting the hose rubberâ mean the sleeve geometry and assembly method are matched to TIâN sleeves, so no unique machine adjustments are normally needed. - Use the manufacturerâs TIâN crimping specifications (crimp diameter, die set, and press force) for the particular hose construction (4SP/4SH/R13/R15) and size. Those standard TIâN settings ensure correct compression and sealing. - Ensure proper assembly: correct sleeve position, full insertion of the fitting into the hose, and compliance with the noâskive installation instruction. - Verify crimp quality by inspecting crimp profile and performing pressure/test procedures per supplier guidelines. If in doubt, consult the TIâN sleeve technical data sheet or the NSK311/flange supplier for the recommended die and crimp dimensions for the exact hose size to confirm compatible crimp parameters.

45° NON SKIVE SAE 3000 flange end, light series, carbon steel, type NSK311

All products, Fittings for high-pressure hoses/

Additional information

Material	CS – steel (cast iron)
Standard length [m]	2

45° NON SKIVE SAE 3000 flange end (SFL 45), lightweight series, designed for crimping in hoses type 4SP, 4SH, R13, and R15 using TI-N crimping sleeve… Installation: without cutting the hose rubber. Material: carbon steel, galvanized.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
TI-NSK311-12-12	End fitting 45° NON SKIVE SAE 3000 3/4", hose 3/4"	20	350	In stock	Enquiry
TI-NSK311-12-16	End fitting 45° NON SKIVE SAE 3000 3/4", hose 1"	25	350	In stock	Enquiry
TI-NSK311-16-12	End fitting 45° NON SKIVE SAE 3000 1", hose 3/4"	20	350	In stock	Enquiry
TI-NSK311-16-16	End fitting 45° NON SKIVE SAE 3000 1", hose 1"	25	350	In stock	Enquiry
TI-NSK311-20-16	End fitting 45° NON SKIVE SAE 3000 1.1.4", hose 1"	25	280	In stock	Enquiry
TI-NSK311-20-20	End fitting 45° NON SKIVE SAE 3000 1.1/4", hose 1.1/4"	32	280	In stock	Enquiry
TI-NSK311-24-20	End fitting 45° NON SKIVE SAE 3000 1.1.2", hose 1.1/4"	32	210	In stock	Enquiry
TI-NSK311-24-24	End fitting 45° NON SKIVE SAE 3000 1.1.2", hose 1.1/2"	38	210	In stock	Enquiry
TI-NSK311-32-24	End fitting 45° NON SKIVE SAE 3000 2", hose 1.1/2"	38	210	In stock	Enquiry
TI-NSK311-32-32	End fitting 45° NON SKIVE SAE 3000 2", hose 2"	50	210	In stock	Enquiry
TI-NSK311-40-32	End fitting 45° NON SKIVE SAE 3000 2.1/2", hose 2"	50	175	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

45° NON SKIVE SAE 3000 flange end (SFL 45), lightweight series, designed for crimping in hoses type 4SP, 4SH, R13, and R15 using TI-N crimping sleeve… Installation: without cutting the hose rubber. Material: carbon steel, galvanized.
