Hose end for high-pressure gases with thread according to DIN477, stainless steel, type ZBW170
End fitting for thermoplastic and hydraulic hoses intended for high-pressure gases with internal thread G-3/4″ (3/4″ – BSP), connection according to PN-81/M-69229 (DIN477-1 no. 9). Application: oxygen, carbogen. Material: Material: AISI 304 steel – fitting, brass – nut.
List of product variants
| Article number | Product variant name | Nominal inner diameter | Working pressure [bar] | Enquiry |
|---|---|---|---|---|
| TI-ZBW170-12-04-SS-MO | End fitting GW3/4" BSP DIN477, for hose 1/4", AISI 304 (brass nut) | 6 | - | |
| TI-ZBW170-12-05-SS-MO | End fitting GW3/4" BSP DIN477, for hose 5/16", AISI 304 (brass nut) | 8 | - | |
| TI-ZBW170-12-06-SS-MO | End fitting GW3/4" BSP DIN477, for hose 3/8", AISI 304 (brass nut) | 10 | - | |
| TI-ZBW170-12-08-SS-MO | End fitting GW3/4" BSP DIN477, for hose 1/2", AISI 304 (brass nut) | 12 | - |
Additional information
| Material | SS – stainless steel |
|---|
