Pneumatic hose with high chemical resistance PVDF
Hose with excellent temperature resistance and strength under elevated pressure made from a special, non-flammable polymer. It has a calibrated outer diameter. The material is resistant to aging and UV radiation, exhibiting good sliding properties which counteract material wear. The material is impermeable to gases, resistant to most concentrated bases and inorganic, organic acids, alcohols, and solvents at elevated temperatures. It has electro-insulating properties. The calibrated outer diameter allows for connection with plugs or fittings from leading manufacturers. Dimensional accuracy ensures consistent compressive strength even for hoses with larger diameters, making it suitable for a wider range of practical applications. Hose material: polyvinylidene fluoride PVDF. Working pressure: from 16 bar to 80 bar (depending on hose diameter). Operating temperature: from -50°C to +140°C.
List of product variants
| Article number | Product variant name | Nominal inner diameter | Working pressure [bar] | Enquiry |
|---|---|---|---|---|
| NP-PVDF-04X02 | PVDF hose 4x2 mm | 2 | 126 | |
| NP-PVDF-08X06 | PVDF hose 8x6 mm | 6 | 48 | |
| NP-PVDF-12X10 | PVDF hose 12x10 mm | 10 | 31 | |
| ZC-PVDF-04X02 | PVDF hose 4x2 mm | 2 | 80 | |
| ZC-PVDF-06X04 | PVDF hose 6x4 mm | 4 | 40 | |
| ZC-PVDF-08X06 | PVDF hose 8x6 mm | 6 | 26 | |
| ZC-PVDF-10X08 | PVDF hose 10x8 mm | 8 | 20 | |
| ZC-PVDF-12X10 | PVDF hose 12x10 mm | 10 | 16 |
Hose with excellent temperature resistance and strength under elevated pressure made from a special, non-flammable polymer. It has a calibrated outer diameter. The material is resistant to aging and UV radiation, exhibiting good sliding properties which counteract material wear. The material is impermeable to gases, resistant to most concentrated bases and inorganic, organic acids, alcohols, and solvents at elevated temperatures. It has electro-insulating properties. The calibrated outer diameter allows for connection with plugs or fittings from leading manufacturers. Dimensional accuracy ensures consistent compressive strength even for hoses with larger diameters, making it suitable for a wider range of practical applications. Hose material: polyvinylidene fluoride PVDF. Working pressure: from 16 bar to 80 bar (depending on hose diameter). Operating temperature: from -50°C to +140°C.
Additional information
| Material | PVDF – polyvinylidene fluoride |
|---|---|
| Maximum operating temperature [°C] | 150 |
| Minimum operating temperature [°C] | -40 |
| Vacuum resistance | check |
| Standard length [m] | 100, 50 |
