Is the Quick coupling socket 90Â° for injection molds with GZ and valve, DYROS series 6 compatible with both metric and BSP threads?

Yes. The Quick coupling socket 90Â° for injection molds with GZ and valve, DYROS series 6 is available with either metric or BSP external threads, so it is compatible with both metric and BSP threaded connections.

Can Quick coupling socket 90Â° for injection molds with GZ and valve, DYROS series 6 be used with hot water and aggressive cooling fluids up to 15 bar?

Yes. Quick coupling socket 90Â° for injection molds with GZ and valve, DYROS series 6 can be used with hot water and aggressive cooling fluids up to 15 bar. It is specifically designed for cooling liquids in plastic processing, has a working pressure of 15 bar, brass construction with treated stainless steel retaining rings, springs and balls, and Viton seals-materials compatible with many hot and aggressive fluids. Ensure fluid compatibility with brass and Viton for your specific chemicals and confirm temperature limits for Viton to guarantee safe operation.

Does the Quick coupling socket 90Â° for injection molds with GZ and valve, DYROS series 6 require special maintenance or lubrication to ensure sealing and longevity?

Quick coupling socket 90Â° for injection molds with GZ and valve, DYROS series 6 does not require complex or frequent special maintenance, but a few simple care steps will ensure reliable sealing and long service life: - Regular inspection: periodically check the body, valve, retaining rings, springs and balls for wear, deformation or corrosion. Although components are brass and treated stainless steel, damage or contaminants can impair sealing. - Cleanliness: keep the coupling and mating parts free of dirt, debris and residues from cooling liquids. Flush with clean fluid or compressed air before connection to prevent particle damage to the Viton seals and valve seats. - Lubrication: no continuous lubrication regime is required. If lubrication is needed (e.g., after extended storage or heavy use), use a compatible lubricant safe for Vitonâavoid petroleum-based products that can degrade the seal. A light film of silicone or fluorinated grease compatible with Viton is recommended sparingly on moving parts. - Seal care and replacement: Viton seals are chemical- and heat-resistant, but inspect them for cuts, hardening or swelling. Replace seals if any deterioration is found to maintain 15 bar working pressure capability. - Avoid aggressive media: although brass and Viton tolerate many cooling liquids and compressed air, avoid prolonged exposure to solvents or chemicals incompatible with Viton or brass to prevent premature failure. - Pressure checks: periodically test under working pressure (up to 15 bar) to verify leak-free performance, especially after maintenance or seal replacement. Following these straightforward checks and keeping the mating surfaces clean will preserve sealing performance and longevity of the Quick coupling socket 90Â° for injection molds with GZ and valve, DYROS series 6.

Quick coupling socket 90° for injection molds with GZ and valve, DYROS series 6

Additional information

Material	B – brass (bronze)

90° quick coupling socket DYROS series 6 with external thread and shut-off valve. Available with metric or BSP thread. Designed for cooling liquids in plastic processing, compressed air installations, gas cylinders, and other technical fields. Material: all components are made of brass, while the retaining rings, springs, and balls are made of treated stainless steel. Sealing: viton. Working pressure: 15 bar.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
DY-VKUM610-90	90° socket DN 6 with GZ M10x1, with valve	-	15	In stock	Enquiry
DY-VKUM645-90	90° socket DN 6 with GZ M14x1.5, with valve	-	15	In stock	Enquiry
DY-VKUR614-90	90° socket DN 6 with GZ 1/4", with valve	-	15	In stock	Enquiry
DY-VKUR618-90	90° socket DN 6 with GZ 1/8", with valve	-	15	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

90° quick coupling socket DYROS series 6 with external thread and shut-off valve. Available with metric or BSP thread. Designed for cooling liquids in plastic processing, compressed air installations, gas cylinders, and other technical fields. Material: all components are made of brass, while the retaining rings, springs, and balls are made of treated stainless steel. Sealing: viton. Working pressure: 15 bar.
