Is the Hex plug with GW NPT stainless steel, 108H compatible with threaded couplings used in chemical and nuclear power plant systems?

Yes. Hex plug with GW NPT stainless steel, 108H is compatible with threaded couplings used in chemical and nuclear power plant systems. The product description specifies an external NPT thread and design âfor threaded couplings intended mainly for the chemical, petrochemical, pharmaceutical, energy, nuclear power, and process engineering industries,â and the material AISI 316 stainless steel (corrosion- and chlorine-resistant, good mechanical properties at elevated temperatures) is standard for such applications. Compatibility still requires matching thread size, class, pressure/temperature ratings, and any plant-specific material/qualification standards (e.g., ASME, NACE, client nuclear certifications). If those match, the 108H plug is an appropriate choice.

Can the Hex plug with GW NPT stainless steel, 108H withstand corrosion in pharmaceutical and petrochemical process environments?

Yes. The Hex plug with GW NPT stainless steel, 108H, made from AISI 316, offers good corrosion resistance for many pharmaceutical and petrochemical process environments. AISI 316 (marine-grade) stainless steel contains molybdenum, improving resistance to chlorides, acids and many organic chemicals commonly found in these industries. For typical process conditions-moderate temperatures, neutral to mildly corrosive media, and sanitized/pharmaceutical cleaning agents-108H will perform well. Limitations: AISI 316 can suffer pitting or crevice corrosion in highly chlorinated, strongly oxidizing, very acidic or high-temperature chloride environments, and may not be adequate for certain specialty chemicals. Final suitability requires review of the specific process media, concentration, temperature, pressure and any cleaning agents; where extreme conditions exist, higher-alloy materials (e.g., duplex, 316L, Hastelloy) or coatings may be recommended.

Does Hex plug with GW NPT stainless steel, 108H meet pressure ratings for energy and process engineering systems?

Hex plug with GW NPT stainless steel, 108H: brief answer. possibly, but not guaranteed from the given description alone. Why: The description (Hexagonal plug with external NPT thread, type 108H, for threaded couplings intended mainly for the chemical, petrochemical, pharmaceutical, energy, nuclear power, and process engineering industries. Material: AISI 316 steel) identifies intended application areas and corrosion-resistant material, but it does not state any specific pressure rating, temperature limits, thread tolerance class, sealing method, or applicable standards (e.g., ASME B1.20.1 for NPT threads, ASME B16.34, EN 10204 certification, PED compliance, or maximum allowable working pressure/temperature charts). What you need to confirm compliance with energy and process engineering pressure requirements: - Explicit maximum allowable working pressure (MAWP) at specified temperatures. - Applicable standards and certifications (PED 2014/68/EU, ASME, API, EN). - Thread class and sealing method (tapered NPT relies on thread interference and sealant; pressure performance depends on correct engagement and sealing). - Inspection and material certificates (e.g., EN 10204 3.1/3.2) proving AISI 316 composition and mechanical properties. - Test reports (hydrostatic or pneumatic tests) and traceability for critical systems (nuclear/pressure-critical). - Connection compatibility with the mating coupling rated for the system pressure. Conclusion: Hex plug with GW NPT stainless steel, 108H alone does not guarantee meeting pressure ratings for energy and process engineering systems without documented MAWP/temperature data, applicable standards/certifications, and test/certification records. To determine compliance, request the manufacturerâs pressure/temperature ratings, standards conformance, and material/test certificates.

Hex plug with GW NPT stainless steel, 108H

All products, Precision threaded fasteners/

Additional information

Material	SS – stainless steel

Hexagonal plug with external NPT thread, type 108H, for threaded couplings intended mainly for the chemical, petrochemical, pharmaceutical, energy, nuclear power, and process engineering industries. Material: AISI 316 steel.

List of product variants

Article number	Product variant name	DN	BAR	Availability	Actions
HM-P108H-02-SS	Blind plug GW 1/8" NPT (hexagonal), SS	-	448	In stock	Enquiry
HM-P108H-04-SS	Blind plug 1/4" NPT (hexagonal), SS	-	455	In stock	Enquiry
HM-P108H-06-SS	Blind plug GW 3/8" NPT (hexagonal), SS	-	366	In stock	Enquiry
HM-P108H-08-SS	Blind plug GW 1/2" NPT (hexagonal), SS	-	338	In stock	Enquiry
HM-P108H-12-SS	Blind plug GW 3/4" NPT (hexagonal), SS	-	317	In stock	Enquiry
HM-P108H-16-SS	Blind plug 1" NPT (hexagonal), SS	-	303	In stock	Enquiry

Do you need a larger quantity of products or a bespoke quote?

Call us: +48 61 653 02 22 or email us: tubes@tubes-international.com

SEND ENQUIRY

Hexagonal plug with external NPT thread, type 108H, for threaded couplings intended mainly for the chemical, petrochemical, pharmaceutical, energy, nuclear power, and process engineering industries. Material: AISI 316 steel.
