EVEREST® hose for acids, bases, industrial alcohols

Additional information

Material

EPM (EPR) – ethylene-propylene rubber

Maximum operating temperature [°C]

100

Minimum operating temperature [°C]

-40

Vacuum resistance

yes

Standard length [m]

40, 50, 60/ 120

Reinforcement

steel spiral, synthetic cover

Suction and discharge hose intended for the transfer of various chemical substances, mainly for acid, base, ketone, formaldehyde, industrial alcohol, and glycol solutions. Frequently used in industrial plants for draining contaminated water and process water. Also suitable for seawater. Inner and outer layer antistatic R≤106 Ω/m. Available pressure version (without steel spiral) – ORLANDO hose. Vacuum: 0.9 bar. Inner layer: black EPM (EPR) rubber. Reinforcement: synthetic cord, steel spiral. Outer layer: black EPM (EPR) rubber. Working pressure: 10 bar. Operating temperature: from -40°C to +100°C.

List of product variants

Article numberProduct variant nameNominal inner diameterWorking pressure [bar]Enquiry
IV-EVEREST-025Hose EVEREST 25x38 mm2510
IV-EVEREST-032EVEREST hose 32x46 mm3210
IV-EVEREST-038EVEREST hose 38x52 mm3810
IV-EVEREST-051Hose EVEREST 51x68 mm5010
IV-EVEREST-063Hose EVEREST 63.5x81 mm6510
IV-EVEREST-076Hose EVEREST 76x95 mm7510
IV-EVEREST-102Hose EVEREST 102x122 mm10010

Suction and discharge hose intended for the transfer of various chemical substances, mainly for acid, base, ketone, formaldehyde, industrial alcohol, and glycol solutions. Frequently used in industrial plants for draining contaminated water and process water. Also suitable for seawater. Inner and outer layer antistatic R≤106 Ω/m. Available pressure version (without steel spiral) – ORLANDO hose. Vacuum: 0.9 bar. Inner layer: black EPM (EPR) rubber. Reinforcement: synthetic cord, steel spiral. Outer layer: black EPM (EPR) rubber. Working pressure: 10 bar. Operating temperature: from -40°C to +100°C.

Additional information

Material

EPM (EPR) – ethylene-propylene rubber

Maximum operating temperature [°C]

100

Minimum operating temperature [°C]

-40

Vacuum resistance

yes

Standard length [m]

40, 50, 60/ 120

Reinforcement

steel spiral, synthetic cover
