Is the Cable for SNOWBLAST snow cannons high-pressure hose compatible with other CAMLOCK fittings or only supplied with C (socket) and E (plug) in AISI 316?

Cable for SNOWBLAST snow cannons Format: The hose is supplied with CAMLOCK type fittings C (socket) and E (plug) in AISI 316 stainless steel in a high-pressure version (60 bar). While the description specifies C and E fittings as supplied, CAMLOCK fittings of the same DN52 size and AISI 316 material are standard and compatible within the CAMLOCK system; therefore the hose can be used with other CAMLOCK-compatible components of the same size/type, provided they match DN52 and the required pressure rating (60 bar) and material (AISI 316). Ensure any alternate CAMLOCK fittings you use are rated for high-pressure operation and compatible with EPDM-lined, double-braided polyester hoses and the specified temperature range (-40Â°C to +80Â°C).

Can the Cable for SNOWBLAST snow cannons high-pressure hose be ordered with different CAMLOCK materials or custom coupling types beyond C and E?

Cable for SNOWBLAST snow cannons: The standard supply includes DN52 highâpressure hose (EPDM inner, double polyester braid, abrasionâresistant yellow outer) with CAMLOCK fittings socket C and plug E in AISI 316 stainless steel, rated 60 bar and usable â40Â°C to +80Â°C. If you need different CAMLOCK materials or custom coupling types beyond C and E, please contact sales-other lengths up to 60 m are available and custom coupling or material options (e.g., alternative stainless grades or nonâstandard connectors) can typically be arranged upon request, subject to technical feasibility and minimum order/lead time. Provide required coupling type/material and application details for a firm offer.

Can the Cable for SNOWBLAST snow cannons high-pressure hose be supplied in lengths up to 60 m and in DN52 sizes like 25, 30, or 40 m?

Yes. The Cable for SNOWBLAST snow cannons high-pressure hose can be supplied in lengths up to 60 m and is available in DN52 sizes with other standard lengths such as 25 m, 30 m, and 40 m. The hose is a special high-pressure water hose designed for snow guns, abrasion-, aging-, rot-, UV-, weather- and ozone-resistant, suitable for continuous operation at 60 bar, flexible at low temperatures (â40Â°C to +80Â°C for water), with an inner EPDM rubber layer, double polyester braid reinforcement, and a yellow abrasionâresistant outer coating for high visibility on snow. It is supplied with CAMLOCK type fittings (socket C and plug E) in a high-pressure version made of AISI 316 stainless steel.

Cable for SNOWBLAST snow cannons

Air and water hoses, All products/

Additional information

Material	SS – stainless steel
Maximum operating temperature [°C]	80
Minimum operating temperature [°C]	-40
Vacuum resistance	no

Special high-pressure water hose for snow guns, resistant to abrasion, aging, rot, UV radiation, weather conditions, and ozone. Designed for continuous operation at high pressure. Flexible at low temperatures. With an outer yellow coating, it is highly visible on snow, even in twilight. Supplied with CAMLOCK type fittings (socket C and plug E) in a high-pressure version of 60 bar made of AISI 316 stainless steel. Other lengths of DN52 hoses are also available (e.g., 25, 30, and 40 m). Maximum hose length is 60 m. Inner layer: EPDM rubber. Reinforcement: double polyester braid. Outer layer: yellow, special abrasion-resistant coating. Working pressure: 60 bar. Operating temperature: from -40°C to +80°C (water).

List of product variants

Article number	Product variant name	Nominal inner diameter	Working pressure [bar]
GH-SNOWBLAST-52-05	SNOWBLAST hose 52 mm x 5 m with CAMLOCK end	50	60
GH-SNOWBLAST-52-10	SNOWBLAST hose 52 mm x 10 m with CAMLOCK end	50	60
GH-SNOWBLAST-52-15	SNOWBLAST hose 52 mm x 15 m with CAMLOCK end	50	60
GH-SNOWBLAST-52-20	SNOWBLAST hose 52 mm x 20 m with CAMLOCK end	50	60

Special high-pressure water hose for snow guns, resistant to abrasion, aging, rot, UV radiation, weather conditions, and ozone. Designed for continuous operation at high pressure. Flexible at low temperatures. With an outer yellow coating, it is highly visible on snow, even in twilight. Supplied with CAMLOCK type fittings (socket C and plug E) in a high-pressure version of 60 bar made of AISI 316 stainless steel. Other lengths of DN52 hoses are also available (e.g., 25, 30, and 40 m). Maximum hose length is 60 m. Inner layer: EPDM rubber. Reinforcement: double polyester braid. Outer layer: yellow, special abrasion-resistant coating. Working pressure: 60 bar. Operating temperature: from -40°C to +80°C (water).
