Is the Flat wide nozzle for coolant, 1/4" system, JETON suitable for continuous use at +65Â°C and up to 3 bar pressure?

Yes. The Flat wide nozzle for coolant, 1/4" system, JETON Format is specified for continuous operation up to +65Â°C and a working pressure of up to 3 bar, so it is suitable for use at those temperature and pressure limits. Ensure installation and operating conditions do not exceed the stated material limits (acetal) or the specified ranges to maintain performance and safety.

Can the Flat wide nozzle for coolant, 1/4" system, JETON be used with oils or only with water-based coolants?

Flat wide nozzle for coolant, 1/4" system, JETON Format - made of acetal, rated for up to 3 bar and operating temperatures to +65Â°C - is primarily designed for water-based coolants. Acetal (POM) has good resistance to many oils, but compatibility depends on the specific oil type, temperature and additives. Light machining oils and mineral oils are generally compatible at these conditions, while aggressive synthetic fluids, chlorinated hydrocarbons or hot oils may cause swelling or degradation. Before using oils, check the oilâs chemical compatibility with acetal and ensure operating temperature stays â¤65Â°C and pressure â¤3 bar. For critical applications, test a sample or consult the oil supplier/manufacturer.

Does the Flat wide nozzle for coolant, 1/4" system, JETON resist chemical cleaners or solvents?

Flat wide nozzle for coolant, 1/4" system, JETON is made of acetal (POM). Acetal offers good mechanical strength, dimensional stability and resistance to many hydrocarbons, oils and some solvents, and it performs well in typical coolant applications up to +65Â°C and pressures up to 3 bar. However, acetal is not universally resistant to all chemical cleaners or aggressive solvents. it can be attacked by strong oxidizers, some chlorinated solvents, ketones (e.g., acetone), and certain aromatic hydrocarbons. Concentrated acids and strong bases may also degrade acetal over time. Therefore, Flat wide nozzle for coolant, 1/4" system, JETON will resist common coolants and many light cleaning agents, but you should avoid prolonged exposure to aggressive or concentrated chemical cleaners and solvents. For any specific cleaner or solvent, check its compatibility with acetal (POM) or consult the solventâs chemical-resistance data sheet to ensure safe use.

Flat wide nozzle for coolant, 1/4″ system, JETON

Air and water hoses, All products/

Additional information

Wide flat nozzle for coolant hoses JETON – 1/4″ system. Available in size 1″. Material: acetal. Working pressure: up to 3 bar. Operating temperature: up to +65°C.

List of product variants

Article number	Product variant name	Nominal inner diameter	Working pressure [bar]	Enquiry
JT-82027	Flat nozzle with a gap of 25x1.7 mm (1/4" system)	-	3

Wide flat nozzle for coolant hoses JETON – 1/4″ system. Available in size 1″. Material: acetal. Working pressure: up to 3 bar. Operating temperature: up to +65°C.
